Front Load - Automatic Aqueous Cabinets PARTS WASHERS

Octagonal Door Series This unique design allows access to 55% of the exposed turntable when the door is open. Loading by hand or overhead hoist system is easy and fast. 12 Gauge steel construction ensures long lasting durability.

Don't let the low price fool you! These heavy-duty aqueous units strip tough oil and grease from small or large parts easily, quickly and automatically. The turntables rotate at 3 RPM as the parts are blasted with hot soapy water from high-pressure spray nozzles.

FEATURES: All standard features PLUS: powder coat paint, removable parts tree, small parts basket, heavy duty casters, removable debris screen filter included as standard.

T-0100-MINI SYSTEM Exterior H/W/D 54"x38"x36" Interior Height 30" Turntable 24" fixed Capacity 250 lbs Tank Size 30 gal Pump 1HP, 78 GPM, 20PS1 Spray Nozzles 15 Brass Heater 6000 watts	T-0100-MIDI SYSTEM Exterior H/W/D 67"x44"x45" Interior Height 43" Turntable 30" fixed Capacity 500 lbs Tank Size 50 gal Pump 1 HP, 78 GPM, 20PSI Spray Nozzles 18 Brass Heater 6000 watts
T-0100-MINI SYSTEM	T-0100-MIDI
1 Phase-220V System, 50AMP	1 Phase-220V System, 50AMP

T-0100-ER SYSTEMS
Exterior H/W/D 62"x42"x45'
Interior Height 34"
Turntable 26" fixed
Capacity 500lbs
Tank Size 65 gal
Pump 3HP, 60 GPM, 55PSI Spray Nozzles .... 15 stainless steel See Specification Page 10

FEATURES: All standard features
PLUS: 7 day / 24 Hr. programmable digital timers for heater and oil skimmer, low water shut-off switch turns off heater to prevent damage to unit.

T-01 00-ER26	T-0100-ER26-3PH
1 Phase-240V System	3 Phase-240V System

AUTOMATIC FRONT LOAD CLEANING SYSTEMS
